KTM 790 ADVENTURE2024
The 2024 KTM 790 ADVENTURE is designed to make 2-wheeled adventure travel easier. Capable, comfortable, and cost-effective, it not only ticks all the boxes of what an adventure machine should be. instead, it breaks out of the box altogether. Built around a torquey parallel twin-cylinder powerplant, and boasting a class-leading electronics package, it's the perfect choice for riders looking to chase the horizon.
ENGINE
- TORQUE87 Nm
- TRANSMISSION6-speed
- COOLINGLiquid cooled
- POWER IN KW70 kW
- STARTERElectric starter
- STROKE65.7 mm
- BORE88 mm
- CLUTCHPASC™ antihopping clutch, mechanically operated
- DISPLACEMENT799 cm³
- EMSBosch EMS with RBW
- DESIGN2-cylinder, 4-stroke, parallel twin
- FUEL CONSUMPTION4.2 l/100 km
- LUBRICATIONForced oil lubrication with 2 oil pumps
CHASSIS
- TANK CAPACITY (APPROX.)20 l
- ABSBosch 9.3 MP (incl. Cornering-ABS and off-road mode, disengageable)
- FRONT BRAKE DISC DIAMETER320 mm
- REAR BRAKE DISC DIAMETER260 mm
- FRONT BRAKE2x radially mounted 4 piston caliper
- REAR BRAKE2 piston floating caliper
- CHAIN520 X-Ring
- DRY WEIGHT199 kg
- FRAME DESIGNChromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
- FRONT SUSPENSIONWP APEX 43
- GROUND CLEARANCE233 mm
- REAR SUSPENSIONWP APEX - Monoshock
- SEAT HEIGHT860/840 mm
- STEERING HEAD ANGLE64.1 °
- SUSPENSION TRAVEL (FRONT)200 mm
- SUSPENSION TRAVEL (REAR)200 mm
