KTM 390 ADVENTURE
The KTM 390 ADVENTURE takes exploration further by merging all-road versatility and proven reliability with real-world performance. Built around a compact 373 cc single-cylinder powerplant with a capable, lightweight chassis and class-leading electronics, the KTM 390 ADVENTURE encourages you to find new frontiers with the unmatched capability and excitement you'd expected from a KTM ADVENTURE machine. Featuring an updated design for 2022, the KTM 390 ADVENTURE is now also visually aligned with the Dakar winning KTM FACTORY RALLY machines.
ENGINE
- TORQUE37 Nm
- TRANSMISSION6-speed
- COOLINGLiquid cooled
- POWER IN KW32 kW
- STARTERElectric starter
- STROKE60 mm
- BORE89 mm
- CLUTCHPASC™ antihopping clutch, mechanically operated
- CO2 EMISSIONS78 g/km
- DISPLACEMENT373 cm³
- EMSBosch EMS with RBW
- DESIGN1-cylinder, 4-stroke engine
- FUEL CONSUMPTION3.37 l/100 km
CHASSIS
- TANK CAPACITY (APPROX.)14.5 l
- ABSBosch 9.1MP Two Channel-ABS (incl. Cornering-ABS and offroad mode)
- REAR BRAKE DISC DIAMETER230 mm
- FRONT BRAKEFour-piston radial fixed calliper
- REAR BRAKESingle-piston floating calliper
- CHAIN520 X-Ring
- DRY WEIGHT158 kg
- FRAME DESIGNSteel trellis frame, powder coated
- FRONT SUSPENSIONWP APEX 43
- GROUND CLEARANCE200 mm
- REAR SUSPENSIONWP APEX - Monoshock
- SEAT HEIGHT855 mm
- STEERING HEAD ANGLE63.5 °
- SUSPENSION TRAVEL (FRONT)170 mm
- SUSPENSION TRAVEL (REAR)177 mm
